Trident Worm Gearbox

The Trident Worm Gearbox is a excellent gearbox for OEM'S, Machine Builders and Fabricators. Options for hollow bore, single output shafts and dual output shafts available.

Product Code: HHM-090-40:1-180TC

RATIO	40:1
INPUT HP	3
INPUT FLANGE	180TC
OUTPUT BORE DIMENSION	1.375''
Weight	25 lbs

$913.86 CAD

This product qualifies for FREE SHIPPING

Please Call For Availability

Description

Trident Worm Gearbox
Part Number: HHM-090-40:1-180TC

Input Flange: 180TC
Ratio: Ratio: 40:1
Box Size: 90
Output RPM: 44
Input RPM: 1725
Input HP: 3.01
Output Torque: 3330

Dimensions:
A= 5.51
B= 5.31
BA= 5.12
BC= 6.30
BH= 45 Degree
BK= 4.331 0/-0.0021
BL= M10X18mm
C= 3.54
D= 4.06
E= 5.51
F= 3.94
G= 0.43
H= 0.51
J= 8.19
K= 2.91
L= 5.12
M= 5.28
N= 2.76
O= 9.37
P= 5.63
T= 4.02
Z= 6.09
