Leeson Farm Duty Electric Motor 1.5HP 115/230V 1800RPM 56H TEFC

1.5HP 1725RPM 115/230V 56H TEFC 5/8"Shaft

Product Code: 117693

HP

1.5

Voltage

115/230

RPM

1800

Frame

56H

Phase

1

Weight 43 lbs

Please Call For Availability

Leeson Farm Duty Motor
117693

1.5HP
Voltage – 115/230
1725 RPM
56H Frame
1 – Phase
Amps – 13.0/6.6-6.5
Service Factor – 1.15
Efficiency – 0.84
Hz – 60 Hz
Insulation – B
Duty – Continuous
Enclosure – Totally Enclosed Fan Cooled
Thermal Protection – Manual
Ambient Temperature – 40°C
Drive End Bearing – 6203
Non-Drive End Bearing – 6203
CSA Approved – Y
Rotation – Selective Counterclockwise
Mounting – Rigid Base
Material – Rolled Steel
Shaft Diameter – 0.625 in
Shaft Length – 1.87 in

UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Double-shielded bearings extend the service life of the motor.
Single and three phase, TEFC, TEAO, and ODP construction.
Overload protection prevents motor from overheating.

Datapack

117693
